Satori TW29 TXN-B-8 TeXtreme Dome Tweeter

FEATURES

• Advanced TeXtreme® dome
• Two part aluminium faceplate with integrated mechanical decoupling
• Dual balanced compression chambers for improved dynamics
• Dual copper caps for absolute minimum voice coil inductance and minimum phase shift
• High saturation neodymium motor system with T-shaped pole piece for lower distortion
• Non-reflective cast aluminium chamber with optimized damping for
  improved dynamics
• Shallow flow optimized magnet structure for optimum coupling to
  rear chamber
• CCAW voice coil for low moving mass
• Long life silver lead wires
• Low resonance frequency for extended range

SPECS

• Nominal Impedance 8 Ω
• DC resistance, Re 6.2 Ω
• Voice coil inductance, Le 0.04 mH
• Effective piston area, Sd 9.6 cm²
• Voice coil diameter 29 mm
• Voice coil height 2.1 mm
• Air gap height 2.5 mm
• Linear coil travel (p-p) 0.4 mm
• Moving mass incl. air, Mms 0.49 g
• Free air resonance, Fs 680 Hz
• Sensitivity (2.83V/1m) 93.5 dB
• Mechanical Q-factor, Qms 1.63
• Electrical Q-factor, Qes 0.77
• Total Q-factor, Qts 0.52
• Force factor, Bl 4.1 Tm
• Rated power handling* 80 W
• Magnetic flux density 1.5 T
• Magnet weight 0.1 kg
• Net weight 0.4 kg

* IEC 268-5, high-pass Butterworth, 2600 Hz, 12 dB/oct.
