10" SB29NRX75-6

SPECIAL FEATURES:

• Hard paper cone for improved piston operation (made in-house)
• Vented pole piece for minimum compression
• Vented cast aluminum chassis for optimum strength and low compression
• 3” copper voice coil for improved power handling
• Long life silver lead wires
• Low damping rubber surround for improved dynamic linearity
• Non-conducting fiber glass voice coil former for minimum damping

SPECS:

• Nominal Impedance 6 Ω
• DC resistance, Re 4.2 Ω
• Voice coil inductance, Le 1.8 mH
• Effective piston area, Sd 312 cm2
• Voice coil diameter 75.6 mm
• Voice coil height 28 mm
• Air gap height 6 mm
• Linear coil travel (p-p) 22 mm
• Magnetic flux density 0.9 T
• Magnet weight 2.1 kg
• Net weight 5.40 kg
• Free air resonance, Fs 21 Hz
• Sensitivity (2.83V/1m) 88 dB
• Mechanical Q-factor, Qms 5.7
• Electrical Q-factor, Qes 0.38
• Total Q-factor, Qts 0.37
• Moving mass incl. air,Mms 78 g
• Force factor, Bl 10.7 Tm
• Equivalent volume, Vas 102 liters
• Compliance, Cms 0.74 mm/N
• Mechanical loss, Rms 1.8 kg/s
• Rated power handling* 200 W

• * IEC 268-5, T/S parameters measured on drive units that are broken in.

DATASHEET:

Als u deze gegevens liever wilt uitprinten of voor offline gebruik, download dan onze PDF
