This D family tweeter features an 6 ohm 25 mm voice coil, a treated Al dome, large rear chamber for low resonant frequency, and a ferrofluid-cooled ferrite motor. The large motor and rear chamber allow for robust power handling capacity. The tweeter comes with a faceplate with recessed mounting holes, for easy installation into the desired application.

FEATURES

• Aluminum Diaphragm
• Silk Surround
• Ferrofluid Filled Motor
• High Sensitivity
• Grille

SPECS

• Transducer Size (Millimeters) 25.4 mm
• DC Resistance 5.2 Ohm
• Resonant Frequency 721 Hz
• Half Space Sensitivity 94.17 dB
• Rated Noise Power 100 Watt
• Test Spectrum Bandwidth 2K-20K

Als u het complete datablad wilt inzien, download dan onze PDF

Mechanical Dimensions
