This High Definition Sound (HDS) line of products push the performance limits of midbass audio transducers in a range of sizes - from the standard 205mm (8-inch) model, down to the very small 106mm (4-inch) model. Feature-rich and utilizing copper for the lowest distortion possible, the high-end HDS Exclusive Series takes maximum advantage of over 80 years of R&D experience to help systems designers build the world's best audio products. See architecture notes for HDS Platform

FEATURES

• Cast Aluminum Frame
• Vented Cone Neck
• Coated Paper cone
• Ferrite Magnet
• Large Excursion

SPECS

• Transducer Size (Millimeters) 165 mm
• Impedance 8 Ω
• Resonance Frequency 68 Hz
• Sensitivity @ 1W/1m 87.2 dB
• Rated Noise Power 30 Watt
• Frequency Range 80 - 3000 Hz
• Net Weight 1.65 kg

Als u het complete datablad wilt inzien, download dan onze PDF
